Wire

About the product

Copper wire is a key material in modern electrical systems, extensively used in telecommunications, power transmission and magnet wire applications for motors, transformers and inductors.

About the product

Its outstanding electrical conductivity, thermal performance, and durability make it the preferred choice for reliable and efficient energy and signal transfer. The Cu-ETP wire is produced in compliance to specification EN 13601.

More

DensityMelting point40 – 100 Linear expansion coefficientThermal conductivityElectrical resistivityConductivity
8.94 g/cm31,083 ºC0.0165 mm/ºC m.3.9 W/cm ºK17.241 mΩ mm2/m or lower58.0 Siemens (m/Ωmm2) ≥ 101% IACS
Modulus of elasticityTensile strengthElongation
120 GPa> 240 N/mm2min 35%
Diameter (mm)Packing
3.0 – 12.5 mmFree coiled coils
